Cutting motor power |
160/80Kw |
|
Oil pump power |
75Kw |
|
Cutting hardness |
≤70MPa |
|
Cutting range |
Height:4.8m |
|
Width:5.4m |
|
|
Operating weight |
48t |
|
Dimension(LXWXH) |
9.3X2.9X1.6 m |
|
Max Non-removable size(LXWXH) |
3.6X1.66X1.54 m |
|
Max Non-removable weight |
8348 Kg |
|
Cutting head speed |
48/24 r/min |
|
Star wheel speed |
33 r/min |
|
Load capacity |
4.2 m³/min |
|
First transport aircraft speed |
61 m/min |
|
Working speed |
0～6 m/min |
|
Grade ability |
±16º |
|
Gantry height |
400 mm |
|
Underground water pressure |
3-8 MPa |
|
Fuel Tank capacity |
500 L |
|
Ground Pressure |
0.14 MPa |
|
Undercover depth |
0.216m |
|
Ground clearance |
0.25m |
|
Voltage |
AC1140/660V |
