FR260 Excavator
Technical features of FR260
1. Optional imported Isuzu engine from Japan, low fuel consumption, low noise, environmental protection and high efficiency.;
2. Adopted world-classKawasakihydraulic system, high efficient and reliable;
3. High strength structural parts are purchased from the same channels as the world-known brands;
4. Safe and comfortable driving cab;
5. Improved operating performance by many self-owned patented technologies.
|
Parameter Items |
Parameter Value |
|
1.The main parameters |
|
|
Operating weight(Kg) |
25050 |
|
Standard bucket capacity(m3) |
1.2 |
|
ransport dimensions (L × W × H) mm |
9945×3180 ×3255 |
|
Bucket digging force (kN) |
172 |
|
Stick digging force( kN) |
129 |
|
Maximum traction power (kN) |
247 |
|
2.Walking device |
|
|
High and low speed （Km / h） |
4.8/3.4 |
|
Grade ability(°) |
30 |
|
Ground pressure( kpa) |
51 |
|
3.Rotating device |
|
|
Rotating Speed (rpm) |
12.2 |
|
4.Engine |
|
|
Model |
6BG1TRP ISUZU |
|
Type |
6cylinder, in-line/ four-stroke/Direct injection/water-cool/ turbocharged intercooled |
|
Rated power / speed (kW/ rpm) |
125/2100 |
|
Bore × stroke（mm） |
105×125 |
|
Displacement （L） |
6.494 |
|
Fuel consumption（g / KW • h） |
237 |
|
Fuel tank capacity |
385 |
|
5.Hydraulic system |
|
|
Main pump pressure （Mpa） |
32/35 |
|
Main pump flow （L / min） |
240×2 |
|
6.Operation range |
|
|
Maximum digging height（mm） |
10200 |
|
Maximum unloading height（mm） |
7210 |
|
Maximum digging depth（mm） |
6920 |
|
Maximum digging radius（mm） |
10210 |
|
Bulldozing Blade size （L x W ）mm |
/ |
