FL935E Wheel Loader

Technical features of FL935E

1.Equipped with YC6B125-T20 engine;

2.Short wheelbase, small turning radius, flexible, and easy operation in narrow space;

3.Minimum ground clearance is up to 420mm with excellent passing performance;

4.Adopted a large vision, all closed damping cab, comfortable operation environment;

5.Four-wheeled driving, low-pressurewide-baseoff-highway tires with good performance of passing.

Parameter Items

Parameter Value

1.Main parameter



Rated load (kg)

3000

Operating Weight (standard) (kg)

10050

Rated Bucket Capacity (m3)

1.8

Maximum breakout force (KN)

120

Maximum traction force (KN)

92

Total hydraulic cycle time (s)

10.5

Maximum dump height (mm)

2980

Maximum dump distance (mm)

1100

Forward speed range (Km / h)

037

Reverse speed range (Km / h)

028.5

Transport dimensions (L × W × H) (mm)

7066×2424×3230

Maximum steering angle (°)

36

Max. Grade ability(°)

30

Minimum turning radius (mm)

5945

Tire Size

17.5-25-12PR

2.Engine parameter



model

Yuchai YC6B125-T20

Type

6-cylinder, in-line, direct injection and turbocharged

Power (kw)

92

Maximum torque (N.m)

463

Cylinder diameter (mm)

108

Stroke (mm)

125

Output volume (L)

6.871

Fuel consumption ( kw.h)

235

3.Hydraulic system



Work system Pressure (Mpa)

16

4.Braking System



Running braking system type

Single pipeline gas-oil 4-wheel clipper disc braking

Parking / emergency brake system type

Clipper disc braking

5.Fuel Tank Capacity



Fuel tank (L)

155

Hydraulic Tank capacity (L)

180
