ZL50G-7 Wheel Loader
Features of Wheel Loader:
1. Equipped with reliable ShangChai C6121 engine or genuine Cummins engine
2. 4 forward and 3 reverse power shift transmission
3. Bucket automatic leveling ability
4. Combined seal cylinder obtains higher seal performance and more reliability
Specifications of Wheel Loader:
|
Overall Dimension |
|||
|
1 |
Length(with bucket on ground) |
Cummins engine |
ShangChai C6121 engine |
|
|
|
8397(mm) |
8247(mm) |
|
2 |
Width(to outside of wheels) |
2800(mm) |
|
|
3 |
Bucket width |
2946(mm) |
|
|
4 |
Height(To the top of the cab) |
3450(mm) |
|
|
5 |
Wheel base |
3200(mm) |
|
|
6 |
Tread |
2200(mm) |
|
|
7 |
Min. ground clearance |
450(mm) |
|
|
Main Technical Specification |
|||
|
1 |
Rated load |
5000(Kg) |
|
|
2 |
Operating weight |
16400KG |
|
|
3 |
Rated bucket capacity |
3.0(m3) |
|
|
4 |
Max. breakout force |
160kN |
|
|
5 |
Max. dump clearance |
3050(mm) |
|
|
6 |
Dump reach |
1107(mm) |
|
|
7 |
Dump angle at any position |
≥450 |
|
|
8 |
Digging depth(with bucket bottom horizontal) |
210 |
|
|
9 |
Min. turning radius |
||
|
|
(1) Outside of bucket |
5970(mm) |
|
|
|
(2) Outside of rear wheel |
5775(mm) |
|
|
10 |
Pivot angle frame |
400 |
|
|
11 |
Oscillating angle of rear axle |
+11o |
|
|
12 |
Lifting time of bucket |
≤5.8(sec.) |
|
|
13 |
Lowering time of bucket |
≤3.8(sec.) |
|
|
14 |
Dumping time |
≤1.2(sec.) |
|
|
15 |
Traveling speed(Km/h)，4 forward and 3 reverse |
|
|
|
|
(1) 1st gear |
6.7/6.7 |
|
|
|
(2) 2nd gear |
12.2/12.2 |
|
|
|
(3) 3rd gear |
25.6/25.6 |
|
|
|
(4) 4th gear |
39/ |
|
|
Diesel Engine |
|||
|
1 |
Model |
Cummins |
ShangChai C6121 Engine |
|
2 |
Type |
Direct injection. Turbocharged. Water cooling |
|
|
3 |
Rated output |
160 (kW) |
158(Kw) |
|
4 |
Inter-bore of cylinder/stroke |
114/135 (mm) |
121/152(mm) |
|
5 |
Total exhaust of cylinder |
8.3 (L) |
9.7260(L) |
|
6 |
Model of starting motor |
42MT |
KB-24V |
|
7 |
Power of start motor |
8.2(KW) |
7.5(KW) |
|
8 |
Voltage of starting motor |
24(V) |
24(V) |
|
9 |
Rated speed |
2200(r/min) |
2200(r/min.) |
|
10 |
Max. Torque |
975(N.M) |
>843(N.m) |
|
11 |
Starting type |
Electric |
Electric |
|
12 |
Min. specific fuel consumption |
207(g/Kw.h) |
<235(g/Kw.h) |
|
13 |
Engine specific oil consumption |
0.9-1.6(g/Kw.h) |
0.95-1.77(g/Kw.h) |
|
14 |
Net weight |
617(kg) |
960(Kg) |
|
Transmission System |
|||
|
Torque Converter |
|||
|
1 |
Model |
ZF technology WG200 |
|
|
2 |
Type |
3-elements.single stage |
|
|
3 |
Torque ratio |
2.55 |
|
|
4 |
Cooling type |
Pressure oil circulating |
|
|
Transmission case |
|||
|
1 |
Model |
ZF technology WG200 |
|
|
2 |
Type |
power shift, spur gear constant-mesh |
|
|
3 |
Gear shift position |
4 Forward and 3 reverse gears |
|
|
Axle and Tire |
|||
|
1 |
Type of main reducer |
spiral bevel gear, single stage |
|
|
2 |
Gear ratio of main reducer |
4.556 |
|
|
3 |
Type of final reducer |
Single stage planetary |
|
|
4 |
Gear of ratio of final reducer |
5 |
|
|
5 |
total ratios |
22.78 |
|
|
6 |
Max. drawing force |
150kN |
|
|
7 |
Size of tire |
23.5-25-16PR |
|
|
Working Device Hydraulic System |
|||
|
1 |
Model of oil pump |
P257B367ILZA20-6GCXZA10-1 |
323-9121-038 |
|
2 |
System pressure |
20MPa |
|
|
3 |
Model of Multi-way directional valve |
7130-B97 |
|
|
4 |
Pilot valve |
406-1044-1145 |
|
|
5 |
(D*L)Dimension of lifting cylinder |
Ф160*90*715(mm) |
|
|
6 |
(D*L)Dimension of tilting cylinder |
Ф180*90*530(mm) |
|
|
Steering System |
|||
|
1 |
Type |
Middle articulated frame. Co-axis flow amp. Steering |
|
|
2 |
Model of steering pump |
P257-G63467ZAC6/P124-G16ING |
324-9125-017 |
|
3 |
Model of redirector |
Danfoss150G4107 |
|
|
4 |
System pressure |
16MPa |
|
|
5 |
Dimension of steering cylinder |
Ф90*45*435(mm) |
|
|
Brake System |
|||
|
1 |
Type of traveling brake |
Air over hydraulic brake system |
Full hydraulic brake system |
|
2 |
Type of axle brake |
Wet type multi-disc brake in axle |
|
|
3 |
Max. brake oil pressure |
55(kgf/cm2) |
|
|
4 |
Type of emergency brake |
Manual control cutting-off |
Automatic cutting-off oil |
|
5 |
Type of parking brake |
Drum brake |
|
|
Oil Capacity |
|||
|
1 |
Fuel(diesel) |
250(L) |
|
|
2 |
Engine lubricating oil |
Cummins :19(L) |
|
|
3 |
Oil for converter and gear box |
42(L) |
|
|
4 |
Oil for hydraulic system |
220(L) |
|
|
5 |
Oil for driving axles(F/R) |
20/20(L) |
|
