SQ14ZK4Q Truck-Mounted Crane
Parameter
|
Max Lifting Moment |
35 |
t.m |
|
Max Lifting Capacity |
14000 |
kg |
|
Recommend Power Needed At Recommend Oil Flow |
32 |
kw |
|
Max Oil Flow of Hydraulic System |
63 |
L/min |
|
Rated Pressure Of Hydraulic System |
26 |
MPa |
|
Oil Tank Capacity |
220 |
L |
|
Rotation Angle |
(360°)All Rotation |
。 |
|
Crane Weight |
4800 |
kg |
|
Installation Space |
1300 |
mm |
|
Choice of Chassis |
BJ1317VNPJJ-S5福田；NXG1310D3ZEX徐工； |
|
|
Working radius(m) |
2.5 |
4.046 |
5.826 |
7.646 |
9.516 |
11.4 |
|
Lifting capacity(kg) |
140000 |
8400 |
5478 |
4080 |
3148 |
245 |
