SQ12SK3Q Truck-Mounted Crane



Parameter



Max Lifting Capacity

12000

kg

Max Lifting Moment

30

T.M

Recommend Power

30

kw

Max Oil Flow of Hydraulic System

63

L/min

Max Pressure of Hydraulic System

26

MPa

Oil Tank Capacity

160

L

Rotation Angle

All Rotation

Crane Weight

4200

kg

Installation Space

1300

mm

Choice of Chassis

DFL1250A9 东风天龙;DFL1311A3东风 ;CA1240PK2L7T4EA81青岛;EQ5201GFJ6东风;BJ1317VNPJJ-S5北汽福田;BJ5253ZKPJJ北汽福田;DFL1253AX东风;

SQ12SK3Q Lifting capability diagram



Working radius (m)

2.5

4.8

7

9

12.5

Lifting capacity (kg)

12000

6000

3500

2700

1800
