SQ8SK3Q Truck-Mounted Crane



Parameter



Max Lifting Capacity

8000

kg

Max Lifting Moment

20

T.M

Recommend Power

28

kw

Max Oil Flow of Hydraulic System

55

L/min

Max Pressure of Hydraulic System

27

MPa

Oil Tank Capacity

160

L

Rotation Angle

All Rotation

Crane Weight

3300

kg

Installation Space

1200

mm

Choice of Chassis

CA1176PK2L9T3A95 柳特;CA1170PK2L7T3EA80青岛解放;CA1240PK2L7T4EA81青岛;HFC1202KR1K3江淮;EQ5161GFJ7东风;BJ1317VNPJJ-S5北汽福田;EQ5201GFJ6东风;CA1200PK2L7T3EA80解放;LZ1160LCMT东风柳汽;DFL1250A9东风;BJ5317ZNPJJ-S北汽福田;CA1253P7K2L11T1E 解放;EQ1252GFJ东风;

SQ8SK3Q Lifting capability diagram



Working radius (m) 2.5 4.5 7 9 11.5
Lifting capacity (kg) 8000 4400 2500 1750 1100
