SQ3.2SK1Q/K2Q Truck-Mounted Crane



Parameter



Model

SQ3.2SK1Q/SQ3.2SK2Q

Unit

Max Lifting Capacity

3200

kg

Max Lifting Moment

6.72

T.M

Recommend Power

14

kw

Max Oil Flow of Hydraulic System

25

L/min

Max Pressure of Hydraulic System

20

MPa

Oil Tank Capacity

30

L

Rotation Angle

All Rotation

Crane Weight

1172/1316

kg

Installation Space

850

mm

Choice of Chassis

EQ1092FJ1东风;EQ1092FJ东风;EQ1092F3GJ1;NKR77PLLWCJAY 庆铃;DFL1120B东风;EQ1081GJ12D5东风;HFC1083K103R1D江淮;EQ5121GFJ;

SQ3.2SK1Q  Lifting capability diagram

Working radius (m)

2.1

3.25

5.35

Lifting capacity (kg)

3200

1850

950

SQ3.2SK2Q Lifting capability diagram

Working radius (m)

2.1

3.365

5.465

7.565

Lifting capacity (kg)

3200

1800

900

500
