SQ3.2ZK1/SQ3.2ZK2 Truck-Mounted Crane



Parameter

Max Lifting Moment

6.72

6.72

t.m

Max Lifting Capacity

3200

3200

kg

Recommend Power Needed At Recommend Oil Flow

14

14

kw

Max Oil Flow of Hydraulic System

25

25

L/min

Rated Pressure Of Hydraulic System

22

22

MPa

Oil Tank Capacity

60

60

L

Rotation Angle

370

370

Crane Weight

1100

1200

kg

Installation Space

850

850

mm

Choice of Chassis

EQ1092FJ1东风;EQ1092FJ东风;NKR77PLLWCJAY 庆铃;DFL1120B D530东风;EQ1081GJ12D5东风;HFC1083K103R1D江淮;EQ1092F3GJ1东风;EQ5121GFJ东风;

SQ3.2ZK1 Lifting capability diagram

Working radius (m)

2.1

4.15

5.8

Lifting capacity (kg)

3200

1400

1000

SQ3.2ZK2 Lifting capability diagram

Working radius (m)

2.1

4.15

5.8

7.3

Lifting capacity (kg)

3200

1300

950

650
