Model |
NXG5160GJB3 |
|
Drive model |
4×2 |
|
Specificate |
|
|
Max speed（km/h） |
80 |
|
Max grade ability (%) |
20 |
|
Max slope(%) |
20 |
|
Oil tank capacity (L) |
240 |
|
Min ground clearance (mm) |
245 |
|
Electrical system(v) |
24 |
|
Dimension |
|
|
Operating weight(kg) |
8400 |
|
Rated loader weight (kg) |
7400 |
|
Rated weight(kg) |
15995 |
|
Upload specifications |
|
|
Lenth (mm) |
6815 |
|
width(mm) |
2495 |
|
Height(mm) |
3420 |
|
Wheel base (mm) |
3800 |
|
Frame(mm) |
280 |
|
板簧 |
9/10+8 |
|
Main parts |
|
|
Cab |
RUILONG |
|
Engine |
ISDe185 30/ YC6J190-33 |
|
Transmission |
8JS105TA |
|
Front axle |
153 |
|
Rear axle |
153 |
|
tyre |
10.00-20 10.00R20 |
