GR500 Motor Grader
|
GR500
|
|
|
Basic specification
|
|
|
Engine model
|
QSX15
|
|
Rated power/speed
|
399kW/2100rpm
|
|
Dimension(LxWxH)
|
14321×4165×4624mm
|
|
Operating weight(Standard)
|
56000kg
|
|
Performance specification
|
|
|
Travelling speed ,forward
|
0～38(无级变速) km/h
|
|
Travelling speed ,reverse
|
0～38(无级变速) km/h
|
|
Tractive force(f=0.8)
|
370KN
|
|
Max. gradeability
|
30%
|
|
Tire inflation pressure
|
400 MPa
|
|
Working hydraulic pressure
|
22 MPa
|
|
Transmission pressure
|
|
|
Operating specification
|
|
|
Max. steering angle of front wheels
|
左/右49°
|
|
Max. lean angle of front wheels
|
左/右17°
|
|
Max. oscillation angle of front axle
|
上/下15°
|
|
Max. oscillation angle of balance box
|
前/后15
|
|
Frame articulation angle
|
左/右27°
|
|
Min. turning radius using articulation
|
12.4m
|
|
Biade
|
|
|
Maximum lift above ground
|
650mm
|
|
Maximum depth of cutting
|
680mm
|
|
Maximum blade position angle
|
40°
|
|
Blade cutting angle
|
40°—80°
|
|
Circle reversing rotation
|
120°
|
|
Moldboard width X height
|
7300×1067mm
|
All technical parameters are subject to change without prior notice because of technical improvements.
