XM50 Cold Milling Machine



XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.

The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.

Performance and characteristic

⊙Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.

⊙Three-wheeled full driving moving system and the hydraulic differential lock can ensure to be suitable for the poor road conditions with stepless transmission and high/low shift gears,to meet the fast transfer and milling operation requirement .

⊙The steering of the single front wheel ,with small turning radius ,can mill along the manhole covers.

⊙The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.

⊙The imported hydraulic parts and reducers have high working reliability.

⊙Excellent welting milling performance with right rear leg which can be fast swung into the frame makes the milling drum attached to the road edge stone or wall for milling operation.

⊙Hydraulic handheld breakers and rumble strip equipment can be selected.



Model

XM50

Max. milling with
mm
500

Max. milling depth
mm
120
Milling wheel
Number of tools

44
Drum diameter with tools
mm
660
Engine
Model

4BTA3.9-C110
Rated power
kW
82
Rated speed
rpm
2200
Specifications
Operating speed
m/min
0~30
Travel speed
km/h
0~6
Ground clearance
%
60
Ground clearance
mm
≤120
Operating weight
kg
7000
Volume
Fuel tank
L
140
Hydraulic oil tank
L
120
Water tank
L
300
Conveyor
Width
mm

Measurement
Overall machinery LxWxH
mm
3470×1895×3070
Conveyor LxWxH
mm

Travel mode

Tire



All technical parameters are subject to change without prior notice because of technical improvements.
