Cutting motor power |
135Kw |
|
Oil pump power |
75Kw |
|
Cutting hardness |
≤70MPa |
|
Cutting range |
Height:4.74 m |
|
Width :4.84 m |
|
|
Operating weight |
40 t |
|
Dimension(LXWXH) |
8.9X2.8X1.5 m |
|
Max Non-removable size(LXWXH) |
3.53X1.54X1.38 m |
|
Max Non-removable weight |
7625 Kg |
|
Cutting head speed |
44 r/min |
|
Star wheel speed |
33 r/min |
|
Load capacity |
3.4 m³/min |
|
First transport aircraft speed |
61 m/min |
|
Working speed |
0～6.6 m/min |
|
Grade ability |
±18º |
|
Gantry height |
420 mm |
|
Underground water pressure |
3-8 MPa |
|
Fuel Tank capacity |
500 L |
|
Ground Pressure |
0.14 MPa |
|
Undercover depth |
0.2m |
|
Ground clearance |
0.18m |
|
Voltage |
AC1140/660V |
