JP32 Water Tower Fire Truck
JP32 Water Tower Fire Truck is a multi-functional vehicle of hydraulic drive, 360ºfull swing, combined with the function of water tanker, foam tanker and water tower fire truck. The electro-hydraulic proportional control and computer control are applied in the unit. 3-section folding boom, H-shaped outriggers and large box-typed sub-frame are available. Large flow KSP1000 water pump made by Darley company is equipped. The water pipeline for superstructure is arranged along the right side of the folding jib. The electric controlled water monitor is fixed at the tip of the 3rd jib section. The breaker for cutting obstacles is installed on the left front side of the 3rd jib section. Water tanker and foam tanker make the fire fighting operation in a place far away from water source possible. Advanced performance, smooth movements, fine inching control, powerful fire-fighting capacity, safe operations and cable remote control, it is widely used for putting out fire such as those in oil tank area, petrol-chemical plant and large-scale warehouse as well as on high-rise buildings.
Parameter
|
1、Main Technical Data in Travel Configuration |
||||
|
Category |
Item |
Unit |
Parameter |
|
|
Dimension |
Overall length |
mm |
11900 |
|
|
Overall height |
mm |
3995 |
||
|
Overall width |
mm |
2490 |
||
|
Wheel space |
1st, 2nd axle |
mm |
4600 |
|
|
2nd, 3rd axle |
mm |
1350 |
||
|
Track |
Front axle |
mm |
1930 |
|
|
Mid/Rear axle |
mm |
1800 |
||
|
Weight |
Rated fire-extinguishing agent capacity |
Water |
kg |
4000 |
|
Foam |
kg |
3200 |
||
|
Gross weight |
kg |
28750 |
||
|
Axle load |
Front axle |
kg |
7380 |
|
|
Mid/Rear axle |
kg |
21370 |
||
|
Travel parameter |
Chassis |
Steyr King ZZ1322M4646 |
||
|
Engine model |
WD615.87 |
|||
|
Power |
kW/(r/min) |
206/2200 |
||
|
Torque |
N·m/(r/min) |
1160/1300～1600 |
||
|
Max. travel speed |
km/h |
≥75 |
||
|
Min. turning diameter |
m |
≤24 |
||
|
Approach angle |
° |
≥15 |
||
|
Departure angle |
° |
≥10 |
||
|
Braking distance (at speed 30km/h ) |
m |
≤10 |
||
|
Min. ground clearance |
mm |
32 |
||
|
Max. grade-ability |
% |
≥35 |
||
|
2、Main Technical Data for Operation |
||||
|
Category |
Item |
Unit |
Parameter |
|
|
Main performance |
Rated working height |
m |
32 |
|
|
Max. working radius |
m |
19 |
||
|
Boom elevating range |
Angle of 1st boom section tohorizontal |
° |
0～80 |
|
