CDZ22/ CDZ22A Aerial Platform Fire Truck
CDZ22 Aerial Platform Fire Truck is designed by absorbing the advanced technology of similar products abroad, combining the conditions of our country and adopting the successful experience of CDZ series.
It is a combination of aerial platform and ladder with 22m rated working height. Compact configuration is suitable for applications in mid/small cities and residential districts. And can meet the requirements of rescuing and fire fighting in buildings lower than 7-storey.
Parameter
1、Main Technical Data in Travel Configuration
|
Category |
Item |
Unit |
Parameter |
||
|
Dimension |
Overall length |
mm |
10250 |
10160 |
|
|
Overall height |
mm |
3650 |
3650 |
||
|
Overall width |
mm |
2500 |
2440 |
||
|
Wheel space |
mm |
5000 |
5360 |
||
|
Weight |
Gross weight |
kg |
14500 |
14800 |
|
|
Axle load |
Front axle |
kg |
4850 |
4900 |
|
|
Rear axle |
kg |
9650 |
9900 |
||
|
Travel parameter |
Chassis |
EQ1141G7DJ2 Dongfeng EQ1141G7DJ2 |
Benz 1523 |
||
|
Engine model |
6BTA5.9 Cummins 6BTA5.9 |
MB OM906LA |
|||
|
Power |
kw/(r/min) |
132/2500 |
170/2300 |
||
|
Torque |
N·m/(r/min) |
610/1500 |
810/1200～1500 |
||
|
Max. travel speed |
km/h |
≥85 |
|||
|
Min. turning diameter |
m |
≤18 |
≤19.4 |
||
|
Approach angle |
° |
≥34 |
≥19 |
||
|
Departure angle |
° |
≥10 |
≥9 |
||
|
Braking distance (at speed 30km/h) |
m |
≤8 |
|||
|
Min. ground clearance |
mm |
248 |
228 |
||
|
Max. grade ability |
% |
≥25 |
≥30 |
||
2、Main Technical Data for Operation
|
Category |
Item |
Unit |
Parameter |
|
|
Main performance |
Rated working height |
m |
22 |
|
|
Rated load on the platform |
kg |
300 |
||
|
Max. working radius |
m |
14 |
||
|
Telescopic boom length |
m |
9.5～16.0 |
||
