TY160 Bulldozer



Features:



•Adopt Steyr WD615-T1-3A engine, featuring strong power, reliable performance, and convenient aftersales services.
•The drive system adopts hydraulic-mechanical drive.
•The electronic monitoring system with sound/light alarm function is very sensitive and the visual monitoring is very convenient.
•The cab seat can automatically adjust the angle and height, and it has the ergonomically designed operation system, which makes it more convenient and easier to operate.
•The new and beautiful hexahedron cab has wide view.
•It can be equipped with straight tilt blade, U-shaped blade, angle blade, and 3-tooth scarifier, applicable to various work conditions.



Parameter:



Items Unit Parameters
Engine Model   WD615-T1-3A
Rated speed r/min 1850
Piston displacement L 9.7
Rated power kW 131
Min. oil consumption g/kW.h 198
Operating weight kg 17,400
Max.traction kN 141
Single blade (straight tilt blade) capacity 3.9
Productivity (haul distance 30m) m³/h 350
Ground contact length mm 2430
Ground pressure kPa ≤65
Track center distance mm 1800
Max.output torque N.m 830
Max.gradeability  ° 30
Min.ground clearance mm 400
Min.turning radius mm 3100
Dimension(incl. scarifier)L×W×H

mm 6430×3416×3015
Travel speed 3 forward gears km/h 0-9.07
3 reverse gears km/h 0-11.81
Max.lifting height mm 1149
Max. scarification depth mm 545
Scarifier teeth piece 3

    Drive System

Hydraulic torque converter 3 components, single-stage, singlephase
Transmission Planetary gear, multi-disc clutch, hydraulic integrated forced lubrication
Main drive Spiral bevel gear, first-stage speed reduction, splash lubrication
Steering clutch Wet, multi-disc, spring-pressed, hydraulic release
Steering brake Wet,band type,auxiliary foot pedal, with parking brake
Final drive 2-stage spur gear reduction, splash lubrication

    Travel System

Type Sprayed beam swing type, equalizing beam suspension structure
Track Single grouser combined
Grouser height 60mm
Amt.of track shoe 37x2
Track shoe width 510、560、610mm
Pitch 203mm
Amt.of carrier wheel 2/each side
Amt.of supporting wheel 6/each side

    Working hydraulic system

Working oil pump PAL.112 gear pump
Cylinder Double acting piston type
Max.working oil pressure 14MPa
Blade hoisting inner bore×quty. 110mm×2
Tilting cylinder inner bore×quty. 160mm×1
Soil loosening cylinder inner bore×quty. 160mm×1
Control valve Duplex spool type
