>>> Current Position : Products
|
Model |
XZ160A |
|
|---|---|---|
| Engine |
shangchai |
|
| Rated power |
kW |
100 |
| Max.pullback/thrusting |
kN |
160/100 |
| Spindle torque(max) |
N.m |
5000 |
| Spindle speed |
r/min |
0-180 |
| Backreaming diameter |
mm |
Ø600 |
| Tubing length(single) |
m |
3 |
| Tubing diameter |
mm |
Ø60 |
| Entry angle |
° |
10-23 |
| Mud flow rate(max) |
L/min |
160 |
| Mud pressure (max) |
bar |
100 |
| Overall weight |
kg |
6100 |
| DIMENSION (LxWxH) |
mm |
5700×1820×2400 |
