SQ4ZK2 Truck-Mounted Crane



Parameter





Max Lifting Moment

8.4

t.m

Max Lifting Capacity

4000

kg

Recommend Power Needed At Recommend Oil Flow

14

kw

Max Oil Flow of Hydraulic System

25

L/min

Rated Pressure Of Hydraulic System

26

MPa

Oil Tank Capacity

60

L

Rotation Angle

370

Crane Weight

1200

kg

Installation Space

850

mm

Choice of Chassis

EQ1092FJ1东风;EQ1092FJ东风;DFL1120B D530东风;EQ1081GJ12D5东风;HFC1132KR1K3江淮;LZ1120LAPT东风柳汽;HFC1083K103R1D江淮;EQ1092F3GJ1东风;EQ5121GFJ东风;

SQ4ZK2 Lifting capability diagram



Working radius (m) 2.1 4.15 5.8 7.3
Lifting capacity (kg) 4000 1840 1260 920
